Electra 150 LBS Chocolate Melanger Nut Butter Grinder - with Speed Controller

8500
$8,500.00
Lighter Grinding stone
Efficient Grinding
Compact Design
Easy to use

Click here for User Manual

- +
Availability:In stock
SKU ECM150
Details

Product Description





The ideal machine for cocoa processing and nut butter processing and other multipurpose grinding needs..Chocolatieurs and foodies need for controlling the speed of the conching process, and we made it. The newly developed 2021 model with an electronic speed controller unit allows the drum rotation speed to be varied from zero to full speed with extra added features.



This 130 Litres empty drum volume capacity machine is the perfect companion to enterprise and can grind up to approx 100 lbs of cocoa bins. The classic Titling feature makes it unnecessary to have to lift the vessel or drum to pour out the contents. Simply tilt and pout it out and avoid straining yourself. Cleaning is a breeze, simply pour water, run the grinder for a few seconds and pour out the water. It almost cleans itself. Solid 100 % SS 304 Stainless Steel body provides elegance, strength and durability. In addition, this grinder has all the features that make it stand out like powerful motor, gear drive, exhaust system, black granite stone for long life and high quality internal and external components.



Tension of the granite stones can be adjusted to obtain different grades of shear at different stages of grinding and for different ingredients.Double granite roller stones and only model with double scrapper that rotate over a granite base. This creates quick tremendous shear that reduces the cocoa nibs to fine chocolate liquor and nuts into paste with a particle size of the order of less than 15 microns.



Speed controller and control panel is provided as standard with the unit, and comes with built in electrical MCB protection. This unit helps you to set the machine speed for different processing and adjust the quantity of ingredients. This is very much useful for you to differentiate your process from others, and make your recipe and processing unique to yourself.



The machine works as a conch and a refiner. The tension from the stones can be fully released for the conching cycle without grinding further, such that the cocoa liquor is continuously exposed to air without grinding it further and the volatile s are removed. All models have this feature and there is no need for a separate model or attachments to buy. There is no need to buy any additional add-on's or attachments, and all are included.



This amazing stone  grinder is the perfect companion to your endeavor. We have made several key enhancements to the grinder to make it perfect for Chocolate, nut butters, mexican masa, cosmetics and other food processing. Our stone melangers can be used to make Marcepan from almond, Mesa from corn, coconut paste, Gianduja from hazel nuts, Pistachio and cashew butters, Tahini from sesame seeds, flax seeds paste, Sphagnum moss for facials, Hummus from boiled chick peas, rice batter from rice, Quinoa and many an other grinding application.



Features - Cocoa Nut Butter Grinder -Electra 150 with Spped Controller



  • Long, trouble free operation with GEAR drive for heavy duty with heavy duty GEAR BOX. No rubber belts are used

  • High grade rust proof Stainless steel drum with food grade plastic components. No Plastic components in contact with food only SS 304 grade stainless Steel 304 grade hub as a standard.

  • Solid and heavy steel frame

  • Motor does not get overheated even under long and heavy use

  • Tilting feature  lets you to tilt the entire unit for easy removal of contents and easy cleaning

  • Real and naturally occurring Black Granite Stone is used to prevent chipping or thinning and long life. No artificial stones.

  • NO NEED TO BUY ANY ADD ON and ATTACHMENTS - all are included

  • Multipurpose machine that can be used with various food ingredients

  • CE certified motor

  • Speed controller drive made by the world leader and CE & UL certified

  • Ergonomic design

  • Machine can be operated without the lid on if necessary. Lid can be removed while running.

  • Detachable Cylindrical Granite Roller Stones assembly can removed for easy cleaning

  • Spring loaded adjustable load system for efficient grinding and control

  • We have readily available spare parts that can ship worldwide and give you peace of mind



Specifications - Electra 150 Cocoa Nut Grinder



  • Input voltage:  440 Volts, a powerful 3 HP, CE certified motor

  • Rotation of drum at maximum speed is approximately 200 RPM

  • Comes standards with electronic speed controller and MCB protection

  • Empty Full Drum Volume -18 inches wide by 24 inches deep - 130 Litres Empty Drum Volume

  • Grinds up to 125 - 150 lbs of Cocoa

  • Weight - Approximate 450 lbs (425 kgs) , Dimensions - approx LBH  (52 x 27 x 60) inches

  • Crated dimensions (With Wooden Packing)-  41L x 30W x 62H inches



Delivery - Electra 150 Cocoa Grinder



  • Electra 150 is delivered to nearest possible (via Air Cargo) or (via Sea Cargo) only.

  • Dispatch time is 3-4 Weeks.



Cost Includes - Special Notes



  • The advertised is CIF price. Cost + insurance + Freight Charges.

  • Import Duty , local tax, clearance is paid / taken care by Customers.



 ELECTRA MELANGER REFINER - MODELS COMPARISON CHART





S No

Model

Unit Size (L*B*H)

in Inch

Drum size (H*D) in Inch

Empty Drum Volume without Stone in Litre

Input Grinding Capacity in Lbs  of Cocoa

Power in HP

Input Voltage Rating

Machine Weight in kg

1

Electra 20

32*22*45

12” H * 14” D

30 L

25 Lbs

0.5 HP

1φ, 220V/50Hz, 3.5A & 1φ, 110/60Hz, 6A

180 Kg

2

Electra 30

32*23*36

13” H * 14” D

32 L

30 Lbs

1 HP

1φ, 220V/50Hz, 4.5A & 1φ, 110/60Hz, 12.5A

190 Kg

3.

Electra 40

39*28*50

14” H * 16” D

45 L

40 Lbs

1 HP

1φ, 220V/50Hz, 6 A & 1φ, 110/60Hz, 12.5 A

220 Kg

4.

Electra 65

39*28*52

15 ½" H * 18” D

64 L

55 Lbs

1.5 HP

1φ, 220V/50Hz, 3.5A & 1φ, 110/60Hz, 14.5A

240 Kg

5.

Electra 100

39*28*54

18” H * 18” D

75 L

75 Lbs

2 HP

1φ, 220V/50Hz, 4.5A & 1φ, 110/60Hz, 19.5A

250 Kg

6.

Electra 150

52*27*60

18”H * 24” D

130 L

100 Lbs

3 HP

1φ, 440V/50Hz

425 Kg

7.

Electra 200

52*29*66

24”H * 24” D

175 L

150 Lbs

3 HP

1φ, 440V/50Hz

525 Kg



FREQUENTLY ASKED QUESTIONS



 1.Is Electra available in 110V/60Hz?

 Yes, Electra is available in both voltages 440V/ 50Hz and also available in 110V / 60Hz.

 2. Is there any additional Charges?

No hidden prices and no more additional charges, all are inclusive in one price like taxes, shipping cost, etc. You have to pay only advertised amount only in the website.

3. How long I can get the machine?

Electra 150 is a commercial machine, dispatch time is 2 to 3 weeks and 3 to 4 week for delivery time(via sea)

4. What kind of stone is used?

Electra 150 is specially designed to grind cacao and nut to get smooth butter and cream chocolate. Electra 150  is having Hard Black Granite cylindrical stone rotates over the hard black Granite stone base drum.

5.What is grinding capacity of Electra 150?

The Capacity of Electra 150  is 100Lbs.

6. What is the maximum running time of Electra 150?

Usually, Electra 150 runs up to 24 Hours. Since Cacao grinding, nut butter process are hard to grind, Electra 150 is designed for this purpose of continuous grinding to get the smooth and soft chocolate and nut butter.

7. What is function of Electra 150?

Chocolate Grinding, Nut butter grinding, Pea nut grinding, Chocolate Mixing, Almond butter Grinding and all chocolate conching process.

8. What is detailed technical specification?

Electra 150 is a 440 Voltage single phase table top Chocolate melanger in cherry colour, metallic body grinding capacity is about 100Lbs. Approx the net weight is about 425 Kg.

9. Is it shipped to my home location?

Usually Electra is ship in sea cargo, and delivery up to your nearest sea port. Even our shipping agent help to delivery to your Home step, but additional charges applicable PleaseContact Us

More Information
More Information
Volts 440/110
Capacity Commerical
Shipping World Wide Shipping (220 Countries)
Delivery FREE (2-3 weeks) / Express(3-5 Days)
